| Battery Info |
| Battery Type | LiFePO₄ (Lithium Iron Phosphate) |
| Cycle Life | 6,000+ cycles to 80% capacity |
| Shelf Life | Recharge to 40%–60% every 3–6 months |
| Management System | MPPT controller, BMS, etc. |
| Output |
| Capacity | 2,764.8 Wh (51.2 V / 54 Ah) |
| Inverter Type | Pure sine wave |
| Lifting Power | 7,680 W |
| AC Outlets |
4 × AC 20 A
1 × NEMA TT-30R (120 V / 30 A)
1 × NEMA 14-50R (120 / 240 V, 50 A)
3,840 W max total
|
| USB-C Ports | 2 × 100 W max (requires Hub D1, 700 W rated) |
| USB-A Ports | 2 × 15 W, 5 V / 3 A (requires Hub D1, 700 W rated) |
| Cigarette Lighter / DC5521 |
2 × 12 V / 10 A
24 V / 5 A (requires Hub D1, 700 W rated)
|
| Anderson Port |
1 × 12 V / 50 A
24 V / 25 A (requires Hub D1, 700 W rated)
|
| Input |
| Turbo Charging |
3,840 W max
80% in 45 min @ 59–77°F (15–25°C)
|
| AC Input |
120 V, 50/60 Hz, 15 A max
1,800 W max with bypass
|
| Solar Input |
2 × 1,200 W
12–60 V DC, 2 × 20 A
|
| Car Input | 12 V or 24 V via cigarette lighter port |
| Maximum Input |
Apex 300: 3,840 W max
Apex 300 + 1–6 B300K: 6,240 W max
|
| General |
| App Control | Yes, via WiFi & Bluetooth |
| Scalability | Up to 6 × B300K / B300S / B300 per unit |
| Pass-through Charging | Yes |
| Weight | 83.78 lbs / 38 kg |
| Dimensions | 20.67 × 12.87 × 12.6 in
(525 × 327 × 320 mm) |
| Charging Temperature | 32°F to 104°F (0°C to 40°C) |
| Discharging Temperature | −4°F to 104°F (−20°C to 40°C) |
| Storage Temperature | −4°F to 104°F (−20°C to 40°C) |
| Certification | FCC, UL, TELEC, CE, NTC, RCM, LOA, ICASA |
| Warranty | 5 Years |
